Industrial Cutting Tools

Jadestand Industrial Stationary Cutters are specially designed for continuous use in industrial processes where repetitive tasks are performed at a fixed point on the production line. This model prioritizes durability, making it suitable for high load frequency applications, and ergonomics to meet prolonged physical demands.

  • Constructed entirely from high-grade steel, the Stationary Cutter ensures robustness and reliability in its stationary setup. To address the weight increase compared to portable aluminum models, a balancer is incorporated to maintain ease of use and operator comfort.
  • Additionally, the hydraulic pump of the Stationary Cutter is specially adapted to meet the demands of continuous use, ensuring consistent performance and efficiency throughout its operation. With its focus on durability, ergonomics, and efficiency, the Jadestand Hydraulic Stationary Cutter is a reliable and indispensable tool for repetitive cutting tasks in industrial settings.
Description

Technical Parameters

Cutter Model

S-120

Max. working pressure

60Mpa

Cutting force

293KN

Max. Cutting opening

120mm

Cutting performance(Q235A round bar)

28mm

No-load cutting time

3-5s

Maximum cutting bite angle

550

Net weight

14.8kg

Hydraulic oil

10# Aviation hydraulic oil

Dimensions (LxWxH)

655*185*160mm

Stationary pump

EHP-1500

Working pressure

60Mpa

Low pressure

0.7Mpa

High pressure flow

1.8L/min

Low pressure flow

7.9L/min

Motor power

1.5kw

Voltage

220v (110v/380v optional)

Frequency

50/60Hz

Current

6.8A

Motor speed

1400r/min

Oil tank volume

20L

Standard hose length

6m

Weight

35.5kg

SAFE

  • Tools can be operated by using both hand; enhanced safety during cutting tasks.
  • Dead man’s function to immediately stop the operation when hands are released.
  • Guarded moving parts to further minimize the risk of accidents.

DURABLE

  • Solid blades
  • Highgrade steel body & plunger for endurance
  • Blade greasing grooves for smooth and efficient cutting operations
  • Central bolt with greasing nipple
  • Interchangeable blades for versatile use
  • Highgrade, anodized aluminum body
  • Highgrade steel plunger for endurance
  • Blade greasing grooves for smooth and efficient cutting operations.
  • Central bolt with greasing nipple
  • Interchangeable blades for versatile use

ERGONOMIC

  • Easy to operate.
  • Push button control.
  • Stays on torque due to permanent locking of central bolt.
  • A rotation mechanism that makes it possible to rotate a tool in any direction and under any angle.
  • Use of balancer makes the tool virtual weightless.
